Wicked Clinical Case: POCUS & Prone save the day! #FOAMed, #FOAMcc, #FOAMer

So I get a call from a colleague in the ED at about 2am, telling me about a 39 yr old woman post-arrest. So I start putting on my boots and warming up the car (it’s January in Montreal folks).  Apparently she had presented earlier in severe acidosis, the diagnosis is unclear, but she apparently got 2 units for an Hb of 49, then went into respiratory failure and got intubated. She arrested about 30 minutes later, cause unknown.

I tell the ICU to prepare a bed but I want to see her in the ED first. Twenty minutes later I put probe to patient and see a full IVC with spontaneous echo contrast. On that I tell the nurse to hold the fluids – there was a bag and tubing and a pump with 100ml/hr on it – and turn into a subxiphoid view to see a normal RV and a hypokinetic LV with some WMAs. She has marked consolidations  in both posterior lung fields and B lines laterally, with small effusions and dynamic air bronchograms (indicating patent airways). At this point she has a HR of about 120, but there is neither perceptible BP (by NIBP) nor saturation. She’s on levophed at 20mcg. She’s about an hour post arrest which was witnessed and brief (<10min to ROSC).

The theories about the arrest are possible hyperkalemia: she was intubated with succinylcholine before the K of 6.1 was back from the lab, and her pre-intubation pH was 7.0, and post-intubation she was only ventilated at 400 x 18, possibly precipitating a drop in pH and a rise in K. Her EKG had some nonspecific signs at this point, but also a poor anterior R wave.

So we head to the ICU, as instrumentation was needed. Cerebral saturation (SctO2) is 42% and ETCO2 is 20mmhg, which reassures me that the BP is probably in the measurable range (normal SctO2 is >60% and varies, but 47% is certainly viable)…  A jugular CVC with continuous ScVo2 and a femoral arterial line goes in:

screen-shot-2017-01-05-at-10-44-50-pm

So with a BP of 59/44 (ignore the 100/46, not sure whose arm that was on!) I start epinephrine, as the POCUS is similar, as I want some added beta-agonism. ScVO2 matches SctO2 in the 40’s. We get the BP up the the 90-1oo range, the ETCO2 goes to 30, the SctO2 and ScVo2 go up into the high 40’s, which is very reassuring, because with this I know that my epi drip is improving perfusion and NOT over-vasoconstricting. Without looking at a real-time tissue perfusion index of some sort or other, it is nearly impossible to know rapidly whether your therapy is helping or harming (will discuss tissue saturation & resuscitation monitoring in more detail in another post sometime soon).

screen-shot-2017-01-05-at-10-46-31-pm

So now the sat finally starts to record in the low 60’s. We have a PEEP of 5, so start bringing it up. We hit 16 before the BP starts to drop, and that only gets us to the mid 70’s sat%. She actually squeezes my hand to command.

screen-shot-2017-01-05-at-10-45-21-pm

At this point I take a few seconds to recap in my mind. I’d spoken to the husband briefly and she had had recurrent episodes of feeling unwell with headache, nausea and diaphoresis, and that had been out for dinner earlier and she felt fine until later in the evening when this came on and eventually brought her to hospital. There was also a notion of hypertension at an ER visit a couple of weeks ago. Her history was otherwise not significant. Nonsmoker.

Pheo? Maybe, but shock?  I repeat the EKG, and now, in I and AVL, there is perhaps a 1mm ST elevation. She’s 39 and essentially dying. Lactate comes back >15, pH 6.9.  I give her a few more amps of NaHCO3. You can see the BP respond to each amp. I decide we need to go to the cath lab and get the cardiologist on call to get on the horn with the interventional team at a nearby hospital with a cath lab and ECMO, which is what I think she needs. Hb comes back at 116, making that initial 49 that prompted 2 PRBCs probably a technical or lab error…very unfortunate. There are no visible signs of significant bleeding.

But back to the patient, because this isn’t really a transferrable case.

Recap: a 39yr old woman in cardiogenic shock AND in severe congestive heart failure exacerbated by fluids and packed red cells, with a PO2 in the 40’s and sat in the 70’s.

So I decide to prone her.

screen-shot-2017-01-05-at-10-47-44-pm

Along with draining tamponades, this had to be one of the most rapid and rewarding maneuvers I’ve done. There was a scry drop of sat to the 40’s for a few seconds (may have been a technical thing), but then within a few minutes: BP to the 130’s, SctO2 to 59% and sat 100%!

screen-shot-2017-01-05-at-10-46-46-pmscreen-shot-2017-01-05-at-10-47-31-pm

screen-shot-2017-01-06-at-12-08-05-am



We dropped the vasopressors, the FiO2, and all breathed a collective sigh of relief. Now for the novices out there, prone ventilation improves VQ mismatch by moving perfusion from diseased, posterior lung fields to now-dependant, relatively healthy, anterior lung fields.

So transfer at this point was in the works. I planned to leave her prone until the last minute. The miraculous effect started to slowly wane within about 30 minutes, with sat and BP creeping down. At the time of transfer, we were back up to 80% FiO2.

So why is this?  Simple enough, this being simple pulmonary edema – rather than consolidated pneumonia – it migrated to dependent areas  relatively quickly. This was confirmed by a quick POCUS check:screen-shot-2017-01-05-at-10-48-06-pmscreen-shot-2017-01-05-at-10-48-26-pm

So in the still shots, you see a pristine “A” profile (normal, no edema) from the patient’s back, and a severe consolidation or “C” profile with ultrasound bronchograms in the antero-lateral (now dependant) chest. Impressive. (for those wanting some POCUS pearls see other posts and here). This is the reverse of her initial POCUS exam.

So we flipped her back and transported her – lights & sirens – the the cath lab, where they were waiting with ECMO cannulae. As an aside, it was quite refreshing to speak to the ICU fellow who spoke POCUS as well as french and english – it’s not usually the case, but I’m glad to see the change. I do believe it to be a direct effect of the influence of my friend and mentor, Dr. Andre Denault, one of the POCUS deities.

So she turned out to have a normal cath and a large adrenal mass. She did well on ECMO, being weaned off it today, and is now alpha-blocked and waiting for surgery, neurologically intact for all intents and purposes. A big thanks to the interventionists and the ICU team at the Montreal Heart Institute. Puts a smile on my face.



Take Home Points:

  1. don’t resuscitate without POCUS. I wouldn’t want anyone guessing with my life on the line, would you?
  2. keep pheo in mind as a cause of “acute MI” and shock
  3. if you’re not using some form of realtime monitor of perfusion (continuous CO, SctO2, ETCO2, ScvO2) then all you’ve got is looking at the skin and mentation, so you are essentially flying blind. Lactate and urine output are not realtime in real life.
  4. get ECMO in the house, it’ll come in handy. I’m working on it.



Love to hear some comments!

cheers



Philippe



ps I’ll try to add more ultrasound clips from this case in the next few days.

Volume responsiveness and volume tolerance: a conceptual diagram. #FOAMed, #FOAMcc, #FOAMus

So I know I’ve belaboured the point about the difference between volume responsiveness (i.e. will there be significant increase in cardiac output with volume infusion) and volume tolerance (is the volume I am considering giving going to have nefarious consequences), because in my opinion, the focus has been – rightly so to some degree – to look for an accurate way of discerning responsive patients from non. Of course this is absolutely necessary, as one does not want to give volume if it will not have any benefit, but the too-common corollary to that is to automatically give volume to those who are responsive.  Here is an earlier post about this:

https://thinkingcriticalcare.com/2014/10/06/fluid-responsiveness-getting-the-right-answer-to-the-wrong-question-foamed-foamcc-foamus/

So in discussing with a bright young colleague yesterday, Dr. St-Arnaud (@phil_star_sail), I realized that there may be a common conception that physiologically, the relationship between the two may be the following:

Screen Shot 2016-02-21 at 9.03.01 AM

This would mean that it is safe to give volume until a patient is no longer volume responsive, and even perhaps a bit more. Alternately, the two may be closer:

Screen Shot 2016-02-21 at 9.02.27 AM

This would mean that once can go just till the point where the patient is no longer volume responsive.

Either one of these scenarios would be awesome. That would mean that by using any of the flow or volume variation techniques, arterial or venous, we could pretty much remain safe.

However…

While the above may hold true for healthy subjects, I would contend that in sick people (which is who I tend to deal with, especially when resuscitating shock), that the more likely physiological relationship is the following:

Screen Shot 2016-02-21 at 9.03.28 AM

Hmmm… That would mean that assessing for volume responsiveness would only tell you that there would be an increase in cardiac output, but absolutely nothing about whether it would be safe to do so.

This concept is not a new one by any stretch of the imagination. It’s inferred in the diagnosis of “non-cardiogenic pulmonary oedema.” So what causes this shift? Here:

Screen Shot 2016-02-21 at 9.25.50 AM

So, how do we figure out where the point is? Sorry to say there is no answer that I know of. My friend Daniel Lichtenstein uses the FALLS Protocol (identifying the appearance of B lines during resuscitation) which is the least we should do, but I suspect that at that point, we have already overshot the mark. My adopted mentor Dr. Andre Denault (@Ad12andre, in addition to IVC, has identified portal vein characteristics including pulsatility (lots of stuff in press) to show that the viscera are at risk, but as of yet there is no simple answer. CVP value? Please. CVP tracing morphology? Maybe.

No simple answer. No one-size-fits-all velue to look for. Clinical integration.

In my opinion, one should not, in sick patients, seek to volume resuscitate until the point of no-volume-responsiveness. The old adage of “you have to swell to get well” likely kills a few additional patients along the way, just as much as under-resuscitation. I plead guilty for over-resuscitating patients for years before realizing that being on the flat part of Frank-Starling is 100% a pathological state.

Love to hear your ideas and comments!



Jon-Emile Kenny says:

I like your graphics, it makes the concepts tangible. I think we should try to integrate ‘volume status’ into this framework as well. A physiological purist might say that as soon as you are ‘hypervolemic’, you are volume intolerant, because hypervolemia is an abnormal state which should always be avoided. A functionalist might say that you become volume intolerant as soon as you have physiological embarrassment of any organ system – but how is this determined? My gut is that by the time there are B-lines in the lung, you’ve gone too far. By the time there is abnormality of splanchnic venous return, you’ve already gone too far. I am more of a purist, so in my perfect ICU, I would perform q4-6 hour radio-labeled albumin studies to determine the patient’s true plasma volume. In health, the normal blood volume is about 80 mL/kg [thus, once you’ve given a 70kg man 5 L of NS, you’ve almost certainly replenished his vascular volume]. The moment that the blood volume becomes > 95% the norm, I would call the patient volume intolerant and stop volume expansion and focus on venous tone with pressors, cardiac function with inotropes, etc. To me, this makes the most sense in the pure Guytonian world; if you keep flogging a patient with litre after litre of fluid and the patient’s BP remains low, you are missing something – volume is not the answer – regardless of what an ultrasound shows you:
1. trouble shoot the venous return curve [i.e. too little blood volume, too little venous tone, too high resistance to venous return]
2. trouble shoot the cardiac function [i.e. poor rate, rhythm, contractility, valve function, biventricular afterload]
If you need some objective measure of blood volume before you can call volume status optimized before moving onto the next problem to fix – that’s a radio-labeled albumin.
Maybe I’m crazy.cheers

Jon

Thanks for commenting Jon!

I totally agree, if we knew each patient’s normal blood volume, that would be a starting point.  And of course, that would prevent the over resuscitation of a very dilated and compliant venous system (small IVC on ultrasound). Let us know if you figure out a practical way to do that!

It’s too bad that extravascular lung water doesn’t seem to have panned out – not sure why exactly.





Philippe

Musings with Jon-Emile & Philippe – Fluid Resuscitation: Physiology and Philosophy! #FOAMed, #FOAMcc, #FOAMer

So here, Jon-Emile and I explore a topic I’ve posted about before (http://wp.me/p1avUV-bd) so I can see if a master physiologist agrees with my rationale (…not just my rationale but supported by a ton of literature many choose to overlook!).

Please visit http://www.heart-lung.org for Jon’s awesome physiology tutorials!

Love to hear listeners’ thoughts!

cheers



Philippe

The Great Septic Debate (Part 2): Resolution? #FOAMed, #FOAMcc

So, echoing my thoughts form the end of the debate, Steven adds:

Well, I didn’t expect to see my name in a headline, but I suppose it’s a hazard one should expect when they go spreading their arguments across the interwebs!

In truth, I don’t think that Dr. Lynn and I really think that much differently on these issues. We both desire for the science of sepsis to continue developing and to be better than it is. I, personally, would love to be a part of the clinical trials that use genome-based data to determine which treatment arm a patient belongs in. We both deplore any “old guard” attempting to prevent the onward march of discoveries that make our knowledge and abilities more complete. I am actually sorry that some young scientists feel intimidated and that there is anything less than civility and scientific curiosity in our community. Period.

Likewise, I would be shocked if Dr. Lynn did not at least use the observation of infection, SIRS, and organ dysfunction as physical markers of sepsis and warning signs that intervention is necessary. It will be true for a very long time that it is going to be an interaction between two human beings that initiates the diagnosis and treatment of sepsis. A physician will recognize a patient in distress by some means and start the process. For now, these findings are the best we have, and they should prompt us to intervene before the completely diagnostic test results are available. Even when we have the tricorder, something is going to trigger the doc to pull it out of a pocket and use it.

OK, so I have to admit that Dr. Lynn stung me a little with his characterization of TNF-alpha as a “biomarker”. I would rather say that TNF is one of the heavy hitters in the proteomics of sepsis, and I’ll bet that I can get him to concede that point! It stimulates receptors and causes other actions to take place, it’s synthesis and release are regulated and dysregulated; it’s more than just a marker! And I ABSOLUTELY agree that the failure of TNF-directed therapies stems from the fact that they were given both to patients who could benefit from them and patients who, with better characterization, we would have known had no chance of benefitting. The same goes for high dose corticosteroids, anti-endotoxin antibodies, IL-1 directed therapies, and coagulation based therapies. In fact, that’s what I’ve been teaching my trainees for years – if you can call bemoaning the fact that we can’t yet recognize and separate responders from non-responders teaching. We have a desperate need for understanding better, and the science MUST be encouraged. Again, period. Or full stop, for those of you who have that bent! That is, I think, Dr. Lynn’s argument in a nutshell.

I REALLY appreciate the interchange. It is healthy and necessary. The two of us are aiming at the same thing – fewer people dying from sepsis. I haven’t met Dr. Lynn (though I hope to), but I suspect that he spends more hours in his day formulating and doing the new science, while I spend more hours in my day pushing people who think that it isn’t sepsis until it’s shock and multiple organ failure to do something about it before it gets that far. Those are both important parts of the war, but in the end, it is the same war. And we are allies in it.

Steven Q Simpson

And, soon after, Lawrence reaches for that handshake:

I agree completely with Dr. Simpson. We all teach that a good history, physical, basic lab, and a high degree of vigilance for subtle signs of sepsis are pivotal. This includes the use of awareness campaigns which simplify sepsis to something easily understood and screening protocols to assure vigilance. These are great advances.

I also share Dr. Simpson’s concern about empowerment of naysayers who may use the promulgation of the imperfections of sepsis science as a reason not to move forward with early action based detection protocols.

Relevant TNF-alpga, I have to agree that it likely has a fundamental role in some phenotypes of sepsis including the sepsis-like syndrome generated in Ebola patients.

So Dr. Simpson and I probably agree on most sepsis related issues.

To explain a little further, many years ago our research team applied for an NIH grant to define the dynamic relational patterns of all the lab and vitals over time in infected patients. The reviewers did not seem to comprehend why we wanted to do that since a standard for a single unified phenotype of sepsis was already widely accepted. Yet had they realized the need for these types of complete data sets, the entire time time series matrix of vitals, lab, biomarkers, and treatment for each case would have been acquired in PROcess , ARISE, and Promise. This would have occurred if the entire field of scientists had not convinced themselves they already knew that “sepsis/septic shock ” comprised a unified phenotype, “an entity” “a single condition” “a thing or object” definable by a few static thresholds.

So this is why we say the young should call for reform ASAP of sepsis science (not sepsis awareness) and at the upcoming SCCM. Imagine a mult-center trial where these complete time matrices are generated and we define the phenotypes. We can define the phenotypic subtypes and then examine treatments in relation to these.

One might think of sepsis syndrome as analogous to the syndrome of CHF where there is systolic failure, diastolic failure, hypertensive failure, and valvular failure defined phenotypes of CHF.

Perhaps we might have sepsis with capillary membrane failure phenotype and/or, vascular muscle failure phenotype, coagulation control failure , neutrophilic control failure, TNF-alpha mediated immune control failure.

These are simply general gross simplistic considerations, Discussion points.

However the final conclusion of my original post is that, beginning at this SCCM, we must stop trying to explain away the anomalies caused by the past sepsis dogma and accept that these anomalies ARE counter instances. We must accept that we cannot rely on research which uses billing codes as data or by using retrospective controls at the same time the denominator balloons as a function of awareness.

Then we can finally assure that we do not fool ourselves because the world depends only on us. There is no back up. We must accept that we need a new surge of sepsis research ASAP, and…..in a new direction.

This, along with the effort and dedication of Dr. Simpson team, the Sepsis Alliance, and the SSC (now gathering the entire time series matrix of all the diagnostic and treatment data and not just thresholds) will produce an exciting future. If this happens, it would be great to be a young sepsis scientist in 2015.

So yes Dr. Simpson and I actually agree. We are simply fighting the war on sepsis from different fronts.

Most Respectfully
Lawrence Lynn

Thanks again Steven and Lawrence for what I think was both a really informative AND formative discussion.

Philippe

Is medicine approaching a philosophical crossroads? Critically important meanderings by Dr. Lynn! #FOAMed, #FOAMcc

So I feel really honoured that some fantastically bright and forward-thinking people take precious time out of their days to read my rants, and even more so to leave some comments.  I sometimes feel that the message contained in these is actually more important than what I spewed out in the first place, so here is quite an essay by Dr. Lawrence Lynn:

Excellent. This may be the Critical Care Quote of 2014.

“The N=1 principle: remember that we are never treating hundreds of patients at once, and we do not have to decide what is best for most (which is what an RCT generally answers) but what is best for the one patient we are treating.”

In fact when RCTs use a simplistic unified guessed phenotype as a surrogate of a complex disease (e.g. sepsis) in a highly heterogeneous population of critically ill subjects, one cannot even say that the RCT tells what is best for “most” since the first question a scientist trying to understand the validity of the “true state” under test would say is “most of what”, Of course when a free (unboxed) scientist learns that the true state was defined by a guess the discussion is over.

This SCCM will be the 25th anniversary of the guessed sepsis and septic shock criteria. It marks 25 years of failed and non-reproducible sepsis trials using the guessed criteria as standards. The beribboned SCCM speakers will rise to the podium and speculate on and on about what all of these studies might mean. None of them will formally call for reform of the science. Thomas Kuhn shows us that they cannot call for reform any more than those holding the guessed geocentric model could call for reform. “Though they may lose faith.. they will not abandon the dogma which led them to crisis” .

So it is up to you, the young women and men to speak up and demand reform. 25 years if failure is enough. How long will you sit silently in the audience and listen to P values responsive to guesses from a few well meaning docs from another era.

Stand up as a group at this SCCM and demand reform. Let this anniversary ring in a new chapter in critical care research.

If you have not read this editorial below, read it before the SCCM. No one argues that this is not the true history of sepsis science but no one has the courage to stand up and demand reform.

Maybe the 25 year anniversary of failure as a function of using guesses as gold standards could provide the impetus. The world depends on you. There is no backup.

http://www.ncbi.nlm.nih.gov/pubmed/24383420



Here is the solution for a scientific revolution. First read this guide to Dr. Kuhn’s book “The Structure of Scientific Revolutions”. (especially chapter 4)

http://philosophy.wisc.edu/forster/220/kuhn.htm

Then the young docs (and any of the old guard willing to break from the 25 year old dogma) should move together at the SCCM meeting, and plan to do so before the meeting in social media to collectedly call for reform of the science.

If only one calls for reform, of course grants, promotions, etc can dry up for that person. That is of course what those on academic tenure tracks are afraid of. Young academics are taught to rub elbows with the thought leaders, not to formally and publically question the leaders fundamental dogma. Sure you can go your own way a little off the path, for example, questioning whether or not a given threshold is the right one. However this freedom is a façade, as one cannot question whether there actually is a unified phenotype of “sepsis” definable by simple thresholds without risking much.

However, as Dr. Kuhn teaches, with any reform movement in science, once critical mass is reached there will be no repercussions because the old guard will actually join and move with the paradigm shift. They will even try to lead the shift as they see that leading with the old dogma is not possible and they desire to remain thought leaders and certainly do not wish to be among the last clinging to the old dogma.

The crisis Dr. Kun describes in chapter 4 is upon us. Look around. Do you see that the public cannot help save themselves. It is up to us to begin this revolution. Don’t let this crisis go to waste. Again, it is up to us. There is no back up.

I feel sorry for the Arise team. How much time was wasted? How many man hours? How much time, resources, and good data, which could have been acquired to determine the many actual phenotypes of sepsis was lost. Yet, it was known by some that the unified phenotype of sepsis/septic shock was guessed. Why didn’t anyone tell the ARISE team their “true state” was a guess. Wouldn’t ARISE have been performed differently if that was know to the statisticians.

Why didn’t anyone tell those in Zambia before they treated infected HIV patients with EGDT? Did anyone who came through the supra normal values era really think that Rivers treatment group was representative of the broad population of severely infected patients? One size fits all in sepsis? Really? That doesn’t even work for socks …phenotypes of feet differ.

You men and women are very smart. This blog.. Ollie’s, Scott’s. These are awesome for an old trench warrior – who spent his life at the critical care beside – to read. You understand the complexity. One day you will see that I am one of your greatest allies. You will see that you have been working in a well meaning paternal science and Dr. Kuhn warns of the loss derived from well meaning paternal science. .

I know I cannot expect all of you to rise up and call for reform. Dr. Kuhn says you cannot. He says that cannot happen until another fundamental pathway upon which the science can rest is found. That will not happen until the science moves to identify the varied phenotypes of sepsis.

Once I thought (many years ago) that armed with his teachings we might not be doomed to make the same mistakes. I have learned over the past decades that, while science changes…scientists do not.

One thing I lament is the loss of a good tool like SVcO2. I wrote about the complexity of SVO2 and how to consider these complexities when using SVO2 as a physiologic marker (a tool) in 1985s, This is long before anyone thought one could select a SVO2 value and write a protocol. No one thought in those simple terms in those days. Now, in the era of threshold science, it’s “guess the threshold, come to a consensus on the guess, apply for a grant and…. study it in a RCT (without telling the statistician that the “true state” is a guess)..

All I can say is, don’t let them study bedside ultrasound with the simplistic thresholds and a guessed unified (one size fits all) phenotype or that tool like the SVcO2 might be quickly discredited also..

If you let leaders define their own guessed protocols and control them from a central authority you will wind up using only the tools which they think, as a function of their simplistic “true state” threshold world, are proven..

Respectfully

Lawrence Lynn



Now that’s certainly food for thought at a deeper level!

Lawrence, we will certainly have to discuss SCVO2 at some point – I also agree that, well integrated with other modalities, it can provide insight into hemodynamic optimization.

cheers



Philippe

A Witnessed Arrest: Advanced Bedside Ultrasound. #FOAMed, #FOAMcc, #FOAMus

So I was taking over the ICU in the evening, and as I walked in I hear that an arrest had happened and she was now being wheeled out of the ICU to radiology for a CT head and CT angio. So I didn’t get to do a bedside exam.

The story was that an 84 year old woman who had been admitted for atrial arrhythmia had been noted to have different blood pressure in the upper extremities, and the concerned family had urged to hospitalist to seek additional opinions. At the very moment when she was being examined by but the daytime ICU doc and a cardiologist, she suddenly deteriorated. They were actually in the process of bedside ultrasound, which had been normal aside from a small pericardial effusion, when she became unresponsive, seemed to have some lateralizing signs, became bradycardia and arrested. They got ROSC with an epic within a couple of minutes.

The feeling was that, having been started on one of those NOACs (Eliquis), she had bled and arrested by neurocardiac axis. Definitely reasonable, but given the BP discrepancy, ruling out aortic dissection was also a must.

So here is the scan:

A quick glance reveals an ascending aortic aneurysm with what appears to be a dissection and a visible flap. The CT of the head was normal.  A closer look seems to reveal that the dissection extends into the brachiocephalic trunk.  My colleague discussed with the radiologist who repeatedly told him it was a type A but wouldn’t say anything more (don’t ask…). Just as a reminder, here is the current classification:

aortic dissection class

So in discussion with the family, there was obviously concern about the possible stroke (an early normal CT obviously does not rule out an ischemic infarct) and given that a palpable pulse does not exclude dissection, bedside ultrasound was the next step (also because the radiologist had not clearly pronounced himself on the scan – in all fairness he may have just done a preliminary reading – so here is what we see, with the carotid being in the lower right area of the flow box, and part of the jugular in the left upper.

As a comparison, here is the left side (normal – but inverted – jugular rt and carotid lt).

Clearly, most of the right carotid lumen is actually false lumen of the dissection, with only a small crescentic lumen between 3 and 6 o’clock. Not good.

Here are the basic cardiac views:

subxiphoid

parasternal long axis



We can see a small pericardial effusion which looks textured – likely blood, and essentially normal function.  Now here is a right-sided parasternal view, showing the dissected aneurysm, including the dissected intimal flap:

Now this isn’t a routine view, and honestly I did it after having seen the scan where one can see that the aneurysm abuts the chest wall, which would make it ultrasoundable, and i can’t really say I would have done it without that knowledge. But now I would, if a similar case would present itself. Very insensitive but quite specific.

So I thought this was an interesting case to show, as a rapidly developing clinical picture, and from the point of view of bedside ultrasound, it displays the usefulness of carotid imaging and alternate views – and how simple it is to do.  Unfortunately at her age and given state she was not deemed a surgical candidate and passed away the next day.



thanks for reading!

…to sharpen up your resuscitation and ultrasound skills, don’t forget to come to CCUS 2015, may 1-3 in Montreal, Canada!  Register at http://www.ccusinstitute.org and for more details,http://wp.me/p1avUV-aU



Philippe

Venous Hypertension: The Under-Appreciated Enemy Part 2: Discussion with Jon-Emile

So I posted about this a few weeks ago, and the discussion it brought up with Jon-Emile (www.heart-lung.org) turned out to be way better than the original post, and I just wanted to make sure everyone interested got to see it, so here we go (part 1 is here, for those who didn’t come across it: http://wp.me/p1avUV-bJ):

Jon-Emile



Jon-Emile: This is a great topic for review Philippe!

I have come across this problem, certainly on more than one occasion. I was first introduced to the idea of renal venous pressure and renal hemodynamics as a house-officer at Bellevue Hospital in New York. Dr. Jerome Lowenstein published work on this phenomenon as it pertained to ‘Minimal Change Syndrome.” He used to ‘wedge’ the renal vein and measure renal interstitial pressure in these patients and measured the response to diuresis. It was very enlightening and made me feel more comfortable given more diuretics in such patients. [Am J Med. 1981 Feb;70(2):227-33. Renal failure in minimal change nephrotic syndrome].

I am also glad that you bring up the cranial vault in this discussion, because I have often wondered if the encapsulated kidneys behave in a similar way. That is, as renal interstitial volume increases from edema, if there is some point on their compliance curve [like the cranium] where there is a very marked increase in renal interstitial pressure? I have found a few articles which loosely address this idea, but would be interested if anyone else knew of some. In such a situation, there would be a ‘vascular waterfall’ effect within the kidneys whereby the interstitial pressure supersedes the renal venous pressure [like West Zone II in the lungs]; then, renal blood flow would be driven by a gradient between MAP and renal interstitial pressure [not renal venous pressure]. I know of one paper that addresses this physiology in dogs, and finds the vascular ‘choke point’ to be in the renal venous system and not Bowman’s space.

What’s even more interesting, is that when renal interstitial pressure is elevated is that the kidney behaves in a sodium avid state [i.e. urine electrolytes will appear ‘pre-renal’] and this physiology has been known for at least a century!

Lancet. 1988 May 7;1(8593):1033-5. Raised venous pressure: a direct cause of renal sodium retention in oedema?

There is no good explanation as to why this occurs, but one I read is that the high renal interstitial pressure tends to collapse the afferent arteriole and the decrease in afferent arteriole trans-mural pressure which facilitates renin secretion [just like low blood pressure would]; but that would require a fairly high renal interstitial pressure unless the MAP was concomitantly low.

Again, what I must caution [and I’ve been personally wrong about this] is the reflex to give diuretics when seeing a ‘plump IVC’. When I was treating a woman with mild collagen-vascular-related pulmonary arterial hypertension, community-acquired pneumonia with a parapneumonic effusion and new acute renal failure, I assessed her IVC with ultrasound. It was plump an unvarying. I lobbied the nephrologist to try diruesis based on the aforementioned reasoning, but was very wrong. Her kidneys took a hit with lasix. What got her kidneys better was rehydration. In the end, what happened was her mild PAH raised her venous pressure and the hypoxemic vaso-constrction from her new pnuemonia only made that worse. Her right heart pressures, venous pressure and probably renal venous pressure were undoubtedly high. But I didn’t take into consideration her whole picture. She had a bad infection, had large insensible losses and had not been eating and drinking. She was hypovolemic, no doubt, despite her high right heart pressures. Fortunately, her pneumonia resolved and fluids brought her kidneys back to baseline.

Thanks again for another thought-provoking topic



Me: Great points as usual Jon, and your last one brings up a bit of a concern I have always had. To play devil’s advocate, one could argue that it may have been resolution of the pneumonia and its metabolic sequelae and possibly other treatment that resulted in improvement of her renal failure, rather than the fluid, no? Did her hypoxia resolution decrease PAP back to normal – with IVC dynamics restoring – and relief of renal congestion, and improvement “despite” fluid?

To me, fluid administration must – at least transiently – increase CO to have any effect on the perfusion side. To do so, my understanding is that it has to go from right to left. Because of the pericardium and interdependence, if RAP exceeds LVEDP, we will start to impair LV preload, which sets up the vicious cycle of a shrinking LV and growing RV. If we can’s increase our RT heart output, obviously our LV CO headed to the kidneys can’t increase either. Hence the assumption would have to be that somehow this additional fluid can – by increasing RV preload (without increasing RV size and further impinging LV?) – help overcome elevated PAP and increase right to left flow. To me, hard to believe without a pericardiectomy (on a short time frame, naturally). Hence I struggle with understanding how a really plump IVC with little variation (if significant pleural pressure variation is occurring) can really still need fluid.

I’d really, really like to get your comments on this. I’ve had a number of conversations about this with people – some of them pretty bright – but none satisfying. Am hoping you can point out my flawed thinking.



Jon-Emile: Philippe, you ask very good questions. Your first point is quite valid. I think we have a bias of assigning meaning to a particular intervention because we think that particular intervention will work. For the patient I treated, we administered multiple drugs [oxygen, antibiotics, bronchodilators, we may have even given a dose of steroids] and yet I assign meaning to the fluids given. I think in all patients with complex hemodynamics that there are multiple co-varying interventions that all [hopefully] push the patient in the right direction – making it quite hard to grant significance to one in particular. Yet in the patient I treated, the timing with respect to creatinine change and urine output made it very hard to argue in favor of diuresis. We were checking her creatinine fairly regularly as she was in step-down and we were concerned about the trajectory of her illness. With lasix, her creatinine jumped abruptly on the following chemistry while with fluids, creatinine dropped and her urine output really picked up.

Which brings me to Ulrich’s point. It is well-taken and I hope to have a pulmccm post on this shortly. While the CVP does not have any correlation with volume status or volume responsiveness as you point out, the physiology of the CVP can help explain confusing echocardiographic findings.

All a plump, unvarying IVC with spontaneous inspiration means [if you believe the Guyton, or Magder approach] is that the IVC transmural pressure is remaining on the flat portion of its compliance curve during inspiration.

http://www.biomedcentral.com/content/pdf/cc11824.pdf

In other words, the IVC is at such high volume [on the flat portion] that lowering its transmural pressure [lowering the CVP, raising the intra-abdominal pressure or both] does not cause it to shrink in volume.

The question then becomes why is the IVC in this state? And a great analysis to this question is to consider the determinants of great vein volume [which really is a question of great vein/right atrial pressure or the CVP – which is related to volume by compliance].

There are two primary processes which will raise great vein volume and these flow from the Guyton Diagram 1. excessive venous return 2. poor cardiac function or a combination thereof [its really just inflow versus outflow]. Volume status plays one part of venous return, so certainly, if someone is hugely fluid overloaded, their venous return will be enhanced and this will favour a high great vein volume and high great vein pressure, BUT this will be mediated by cardiac function because if the heart can eject the large venous return it is receiving, then the great vein pressure and volume won’t change or may be low. Conversely, if cardiac function is poor, a patient could have a low venous return [e.g. be hypovolemic or euvolemic] and still have a high great vein volume and pressure – simply, because the heart can’t expel from the thorax what little venous return it receives. Importantly, poor cardiac function can mean almost anything [valve dysfunction, tachycardia with arrhythmia, high afterload, poor contractility, etc.].

To me, the above is the true value of thinking about Guyton and the CVP, so when I approach a patient, I try to think about what their venous return curve looks like [by a clinical exam] and I use a TTE to actually see what their heart function looks like [and to me this is the true power of ICU TTE]. The above also explains why CVP simply cannot be a marker of volume status.

In the patient I was treating, her history and physical really suggested poor venous return [she was clearly with a pneumonia, hadn’t been eating and was euvolemic to dry on examination] yet her great vein volume was high on TTE which meant that her cardiac function was most likely poor [on the Guyton Diagram her low venous return curve would be intersecting a very low, flattened cardiac function curve such that shifts with intra-thoracic pressure would not change right heart pressure at all].

But why was her heart function poor? Why could her right heart not eject what little inflow it was receiving? It was probably a combination of things. The pneumonia probably increased right heart afterload which caused some TR, she was tachycardic so wasn’t getting optimal filling time, she was septic with perhaps some underlying cardiomyopathy, perhaps her diastolic blood pressure was lower than normal [she was an elderly lady with likely stiff arteries] and she wasn’t perfusing her right coronary artery well and was suffering from relative ishcemia] it’s certainly is a lot of hand-waving, but all taken together perhaps plausible.

The antibiotics improved her lung function as did the bronchodilators which lowered pulmonary vascular resistance which improved right heart forward flow, maybe the inhaled beta-agonists increased her contractility, maybe the oxygen also lowered her pulmonary vascular resistance, maybe the steroids sensitized her to catechols and this raised her blood pressure and coronary perfusion pressure which improved her right heart function, but also maybe the fluids? Empirically, and in retrospect, venodilating her with lasix probably really lowered her venous return and this crashed what little cardiac reserve she had. It was improving her venous return with fluids that helped.

Sorry if this post is getting too long …

In terms of ventricular interdependence [an excellent, under-appreciated point in the ICU] I think that you have to be very careful extrapolating whether or not this effect is present from an IVC examination. In a classic paper [that caused much consternation at the time] Pinsky found that right atrial pressure was completely uncoupled from right ventricular end-diastolic volume [why the CVP is a poor indicator of volume responsiveness]. Her is a recent review of that paper by Pinsky himself.

http://www.ncbi.nlm.nih.gov/pubmed/24760121

The take home is that while right atrial volume and pressure [and by corollary great vein volume and pressure] can be high, this may not translate to a right ventricle near its elastic limit. Pinsky offers no good explanation as to why this is, but postulates that it may have to do with the complex RV geometry and how this changes during diastole. So until there is a widely accepted means of assessing RV filling with TTE [like an Ea ratio] which could pick up a restricted filling pattern, this is really hard to call on echo. As you are aware, you could look for a flattened septum or D sign during diastole, but I’m not sure how well that sign predicts a patient’s response to a fluid challenge – it certainly screams caution.

This Pinsky paper also highlights a potential disconnect between the physiology proximal to the tricuspid valve and the physiology below it which is also part of my general reluctance to use IVC volume change as a marker of fluid responsiveness, just as I have total reluctance to use CVP [or its change with respiration] as a marker of fluid responsiveness.

Unfortunately, a lot of the time it comes down to ‘guess and check’ – give fluids or give lasix and see what happens. This is why I firmly believe that determining volume status and volume responsiveness are the hands-down hardest party of ICU medicine.

If you’re still reading, I hope this helps.

One more point. I don’t think I gave a full explanation to one of your questions. Please bear with me as this is exceptionally hard to explain with words [indeed why I made heart-lung.org].

The venous return and cardiac function curves are essentially inverse of each other [that is lowering right atrial pressure increases venous inflow but decreases cardiac outflow] so they approximate the letter X [venous return is the \ and cardiac function is the / & the point at which the two lines intersect make up the CVP and defines cardiac output].

If you consider the patient I described, If we assume her venous return is low [because she is venodilated from sepsis and hypovolemic from low PO] then the venous return curve [\] is shifted leftwards. If we assume her cardiac function is poor the cardiac function curve slope [/] is shifted down and to the right.

When she takes a breath in, the lowering of intrathoracic pressure pulls the cardiac function curve leftwards [lowers its pressure relative to venous return] while the increase in in abdominal pressure with diaphragm decent tends to temporarily increase venous return by decreasing abdominal venous capacitance. This effect shifts the venous return curve in a rightward manner.

If the patient’s venous return curve initially intersects the ascending portion of the cardiac function curve [i.e. she is truly volume responsive] BUT, the intersection is very near the plateau of the cardiac function curve [i.e. the portion of the cardiac function curve that will render the patient non-volume responsive and also favour unvarying respiratory change in right atrial pressure/volume with inspiration], THEN with inspiration it is possible to see the intersection of the two curves on the flat portion of the cardiac function curve [as the cardiac function curve is pulled leftwards and the venous return curve is pushed rightwards], even though she does have some cardiac preload reserve. This would be an example of impaired specificity of IVC volume change with spontaneous inspiratory effort as a predictor of volume unresponsiveness [i.e. a false positive for a plump IVC predicting the lack of fluid responsiveness].

I address this physiology in chapter 6 parts C and D and chapter 8 part F.



Me: Very, very interesting. I think this discussion, as many, show how medicine is not a “hard science” but remains a “pseudo-science”, inherent to the fact that we are blending physics, chemistry, biology and cannot really apply simple principles of flow and pressures when dealing with elastic, muscular systems lined with microscopic coating whose compliance and resistance change from moment to moment and thru effect of neural and hormonal influence. There are simply too many unmeasurable variables to come up with single guidelines and rules.

I think, as you say, that there remains a need for some degree of trial and error, that we are hopefully narrowing with the appropriate application of technology and proper data integration.

I’ll percolate all this and see how I can tweak my mental model!

Thanks a lot Jon-Emile!

Philippe





please visit Jon-Emile at http://www.heart-lung.org

Heart-Lung





cheers!

…and don’t forget to register for CCUS 2015 at http://www.ccusinstitute.org!!!

Philippe
